The Diaphragm Activated 12L Gas Geyser provides a reliable source of hot water with relatively low maintenance. This battery-ignited gas water heater can heat up to 12 litres of hot water per minute through a single outlet.
TYPE D install outdoors with a medium cover
Features:
- Diaphragm activated
- Requires no electricity – flame ignition and geyser functions are battery operated
- 84% energy efficiency
- Neat and compact Stainless steel cover
- LCD temperature display
- Flame failure safety device (FFD)
- Pressure relief protection (to function effectively,
the valve must be set to your water pressure)
Technical Specifications:
- Max gas pressure 2.8 kPa
- Max gas consumption 1.86 kg / hour
- Rated Input 24 Kw
- Water pressure 50-500 kPa
- Water Output (min/max) 6L – 12L / min
- Unit weight 8.0 Kg
- Unit size 685 x 340 x 175 mm
- Packaged weight 9.35 kg
- Packaged size 710 x 395 x 210 mm
- Gas Type LPG
For Installers:
- Cylinder vaporisation rates
(maximum short term use)
48kg = 1,9kg/hr
19Kg = 0,92kg/hr
9kg = 0,46kg/hr - Minimum cylinder size = 19kg
- Minimum regulator size = 4kg/hr
- Minimum ID pipe size
12mm = less than 4 meters
16mm = between 4-14 meters
